Horizontal Directional Drill ( XZ180 )
Horizontal Directional Drill XZ1801. Dong Feng Cummins engine2. Rated Power: 97kw3. Pull-back Force: 18 ton4. Output Torque: 6000N. M5. Max power head speed: 140r/min6. Motor propelled power head7. Operating Weight: 10000kg8. Dimension(L*W*H): 6400*2270*2340mmThe imported engine with original packin......
Send Inquiry
Product Description
Horizontal Directional Drill XZ180
1. Dong Feng Cummins engine
2. Rated Power: 97kw
3. Pull-back Force: 18 ton
4. Output Torque: 6000N. M
5. Max power head speed: 140r/min
6. Motor propelled power head
7. Operating Weight: 10000kg
8. Dimension(L*W*H): 6400*2270*2340mm
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.
1. Dong Feng Cummins engine
2. Rated Power: 97kw
3. Pull-back Force: 18 ton
4. Output Torque: 6000N. M
5. Max power head speed: 140r/min
6. Motor propelled power head
7. Operating Weight: 10000kg
8. Dimension(L*W*H): 6400*2270*2340mm
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.
| Model | XZ180 | |
|---|---|---|
| Engine | CUMMINS | |
| Rated power | kW | 97 |
| Max. pullback/thrusting | kN | 180/180 |
| Spindle torque(max) | N. m | 6000 |
| Spindle speed | r/min | 0-140 |
| Backreaming diameter | mm | Ø 600 |
| Tubing length(single) | m | 3 |
| Tubing diameter | mm | Ø 60 |
| Entry angle | ° | 10-22 |
| Mud flow rate(max) | L/min | 250 |
| Mud pressure (max) | bar | 80 |
| Overall weight | kg | 10000 |
| DIMENSION (LxWxH) | mm | 6400× 2270× 2340 |
