Precision Metal Lathe Universal Turning Lathe for Woodworking Ky400 -1000
Product DescriptionSpecification Model No.KY400-1000Swing over bed400mmSwing over cross slide264mmSwing over gap550mmGap width235mmDistance between centers1000mmBed width210mmSpindle bore52mmSpindle bore taperMT6Spindle noseCamlock D1-5Spindle speeds44-2000rpmWidth of cross slide140mmTravel of cross......
Send Inquiry
Product Description
Product Description
| Specification | |
| Model No. | KY400-1000 |
| Swing over bed | 400mm |
| Swing over cross slide | 264mm |
| Swing over gap | 550mm |
| Gap width | 235mm |
| Distance between centers | 1000mm |
| Bed width | 210mm |
| Spindle bore | 52mm |
| Spindle bore taper | MT6 |
| Spindle nose | Camlock D1-5 |
| Spindle speeds | 44-2000rpm |
| Width of cross slide | 140mm |
| Travel of cross slide | 180mm |
| Width of top slide | 90mm |
| Travel of top slide | 100mm |
| Longitudinal feeds | 0.057-2.784mm/rev |
| Cross feeds | 0.014-0.742mm/rev |
| Metric threads | 0.8-14mm |
| Inch threads | 2-28TPI |
| Leadscrew diameter/Pitch | 30mm/6mm |
| Max .Tool shank size | 25×25mm |
| Tailstock quill stroke/Taper | 120mm/MT4 |
| Tailstock quill diameter | 45mm |
| Tailstock quill taper | MT4 |
| Coolant. pump power | 60 Walt |
| Motor power | 2.0/2.4kw double speed |
| Overall dimension | 1920×740×1180/1200 |
| Net weight | 850/900kg |
| Standard Accessories | |
| 4-jaw chuck & backplate | 1pc |
| Face plate | 1pc |
| Steady rest | 1set |
| Follow rest | 1set |
| Stand | 1set |
| Toolbox & tools | 1pc |
| Micro carriage stop | 1set |
| Working lamp | 1pc |
| Coolant system | 1set |
| Foot brake system | 1set |
| Optional Accessories | |
| Quick change tool post | 1set |
| Turning tools | 1set |
| Taper turning attachment | 1set |
| Digital readout | 1set |
| Lead screw cover | 1set |
packing detail
Warehouse to film
